2' x 4'
Image Ceiling Panel
MRI Series
Transform your windowless MRI space into a calming, patient-centric environment with our Illuminated Image Ceiling Panels. Custom designs and fits available through Amico Lights.
Description
Amico’s Illuminated Image Ceiling Panels provide customizable backlit image tile solutions that transform your MRI suite into a patient-centric environment. This recessed LED lighting system offers a uniform illumination that brings your image display to life. The versatile design allows your ceiling displays to be installed in multiple sizes and configurations to fit any design requirements. Choose from our standard image gallery or work directly with Amico to create your custom design and fit.
Specifications
Input Voltage
- 36 Vdc
Input Current
- 1.1 A
Input Power
- 40 W
Heat
- 136 BTU/hr
Overall Dimensions
- 24" x 48"
Electrical Connection
- Ethernet
Fixture Weight
- 10 lbs
Regulatory Compliance
- Listed - UL 2108 CSA C22.2 No. 250
CE
- Certified - 2014/30/EU
RoHS
- Pending - 2011/65/EU
Storage Temperature
- Minimum -40 °C
- Typical 25 °C
- Maximum 85 °C
Operating Temperature
- Minimum -20 °C
- Typical 25 °C
- Maximum 35 °C
Humidity
- Minimum 5 %
- Maximum 95 %
Warranty
- 5 Years
Photometric
- CCT 5000 k
- CRI 80
- Efficacy 120 lm/W
